HPE Networking Instant On 1960 20p Gigabit CL4 4p Gigabit CL6 PoE 2p 10GBT 2p SFP+ 370W Switch (JL807A)

Differentiator: Ports: 24 x 1 G
Uplink ports: 2 x SFP+ 2 x 10 GBASE-T

Power consumption:
Maximum: 100-127V: 500W: 200-220V: 480W
Idle: 100-127V: 40W: 200-220V: 80W

Input voltage: 100-127VAC / 200-240VAC

Ports: 24 RJ-45 autosensing 10/100/1000 BASE-T ports with 4 ports of IEEE 802.af/at/bt CL6 PoE and 20 ports of IEEE 802.af/at CL4 PoE (IEEE 802.3u Type 100 BASE-TX, IEEE
802.3ab Type 1000 BASE-T, IEEE 802.an 10 GBASE-T);
Duplex: 100 BASE-TX: half or full; 1000 BASE-T: full only 10 GBASE-T: full only 2 SFP+ 10 GbE ports 2 RJ-45 autosensing 100/1000/10 GBASE-T ports

Switching capacity: 128 Gbps

Stacking capabilities: 4H height

Throughput: 95 Mpps

Memory and processor: Single-Core ARM v7 Cortex-A9 @800 MHz; 1 GB DDR3; 512 MB NAND flash; Packet buffer size: 1.5 MB

PoE capability: Total 370 W PoE Power (Up to 240 W of Class 6 or 370 W of Class 4 PoE)

Operating temperature: 0-40°C, 0-10,000 ft

Management features: HPE Networking Instant On Cloud; Web browser; SNMP Manager

Warranty: Limited lifetime warranty with 24X7 phone support for the first 90 days and chat support for the entire warranty duration. Community support is available for the life of the product.

Weight: 4.7 kg (10.4 lb)

Dimensions: 35.05 x 44.25 x 4.4 cm (13.80 x 17.42 x 1.73 in)
